Passive or self-powered, RubiQ system is an ultra-compact 2 way system that can be composed of one SUB28 Band-Pass Subwoofer and two or four Qube3 satellites. RubiQ System is designed to operate in small to medium size indoor installation requiring high quality sound and stylish design.
The SUB28 Subwoofer consists of two long excursion 8” cone driver mounted in a proprietary isobaric band-pass enclosure. The Qube3 consists of one 3.5” full range cone driver mounted in a wood fashion enclosure.
| Frequency response | 42Hz – 22’000Hz +/- 3dB (SUB28: 42 – 180Hz; Qube3: 180 – 22’000Hz) |
| Phase response | 350Hz – 10KHz +/- 45° |
| Maximum peak SPL | 118dB |
| Coverage | Horizontal/Vertical: 100° |
| SUB28 size (WxHxD) | 252 x 450 x 500mm |
| Cabinet finish | 15mm MDF, any colors |
| Weight | 17kg |
| RubiQ3” | 110 x 110 x 80mm |
| Cabinet finish | 15mm MDF, any colors |
| Weight | 0.8Kg |
