NEXT HFA108

The HFA118 speaker is a 8” fully powered PA systems designed to deliver high output and dynamics, extreme linearity and fidelity for unrivalled performance.

Entirely made in Portugal, the HFA108 uses superb quality custom made components, loaded within birch plywood enclosures, and coated by a scratch resistant textured paint to assure an outstanding performance.

The heart of the HFA108 is a powerful, 500Wrms, light weight, highly efficient Class D power amplifier module, with switch mode power supply, that delivers an impressive sonic punch with perfectly balanced, rich and transparent, sound at any volume.

The integrated DSP with A/D-D/A low noise converters, provides 8 selectable Presets (six factory defined and two user defined) that can be accessed by an easy selector, located on the front module panel or real-time edited by a PC, using the supplied Soundware software, via USB remote control. This permits the user to easily customize the sound program, for various applications or different venues. An intelligent automatic standby mode is activated when the amplifier detects no input signal, saving energy and extending the expected work life. With the Soundware software it is possible to edit the six pre-loaded Presets and store it in one of the two free memories. Editable parameters are: input equalization, input delay, input High-pass/Low-pass filters and the “Bass Enhancer” function. A total of 255 units can be controlled simultaneously by the software.

Technical Specifications

Product TypeActive Two-way Speaker
Frequency Response (-6dB)68Hz – 19.000Hz
Nominal Coverage (-6dB)90º x 60º user rotatable
Maximum SPL Pgm/Peak122dB / 128dB (Full-Space) (calculated)
Low Frequency Driver1 x 8″ (200mm) / 2″ (51mm) voice coil, B&C custom speaker
High Frequency Driver1 x 1″ (25mm) exit / 1.75″ (44mm) voice coil, custom compression driver
Amplifier Technology2 channel switched mode class AB with DSP
LF Section PowerRMS: 400W / Program: 540W / Peak: 1080W
HF Section PowerRMS: 100W / Program: 135W / Peak: 270W
DSP TechnologyControlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute
DSP Presets6 Factory and 2 User, selectable via software or rear panel switch
Control TypeVia RS485 and supplied software “SOUNDWARE”
Input ConnectorsSignal: 2 x XLR; Power: 2 x powerCON
Power Input90V – 245V
Mains ConnectorPowercon (Input and Output)
Power Consumption550W
Dimensions (WxHxD)244 x 451 x 288 mm
Net Weight11.9kg
Shipping Weight13.4kg
