The MBR series is designed according to the concept of modules for versatile applications. By using a few of the same elements, we can create structures that achieve various acoustic goals, which is particularly important for bass. Proper arrangement of bass modules allows for, among other things, control of low-frequency beam directivity, maintaining high SPL with increasing distance, and correct addition of low frequencies in the sound-reinforced area. MBR modules are also extremely easy to configure and physically adapted to create cardioid and end-fired structures, which can significantly reduce acoustic pressure behind the basses. A small subwoofer with excellent parameters.
The MBR series is designed according to the concept of modules for versatile applications. By using a few of the same elements, we can create structures that achieve various acoustic goals, which is particularly important for bass. Proper arrangement of bass modules allows for, among other things, control of low-frequency beam directivity, maintaining high SPL with increasing distance, and correct addition of low frequencies in the sound-reinforced area. MBR modules are also extremely easy to configure and physically adapted to create cardioid and end-fired structures, which can significantly reduce acoustic pressure behind the basses. A small subwoofer with excellent parameters.
| Frequency Response (-3dB) | 39Hz – 120Hz * | |
| Frequency Response (-10dB) | 32Hz – 170Hz * | |
| Recommended Frequency Range | 32-100Hz (30Hz BW@24dB/oct – 100Hz L-R@24dB/oct) | |
| Recommended Amplifier Power RMS | 2500-4000W at 4Ω | |
| Recommended Amplifier Model | FAVO MD4420 (up to two MBR218 modules per channel) | |
| Nominal Speaker Power AES/Continuous/Peak | 2400W / 4800W / 9600W | |
| Maximum SPL (peakCF4 12dB) | 140dB ** (limited by amplifier) | |
| Directivity | Omnidirectional or cardioid, depending on the number of modules in the set *** | |
| Speaker | 2×18″ low-frequency, 4″ voice coil, Xmax 10mm, neodymium magnet | |
| Impedance | 4Ω | |
| Dimensions (HxWxD) | 540mm x 1030mm x 820mm (with dedicated rolls) or 720mm (without wheelboard) | |
| Weight | 73kg | |
| Measurement Conditions | Measurements taken for one module in half-space conditions using filters 25Hz BW@24-120Hz L-R@24 | |
