The DLA6 is a compact 2 way line Array loudspeaker. It’s a light, simple and versatile product designed to deliver great sound into medium and even large venues.
The two way full range Loudspeakers consist of 2 x 6.5” low frequency cone driver and a 1.4” exit, 3” voice coil compression driver mounted in a complex Audio Performance Wave Guide that constrains the horizontal directivity into a 100° angle. The specific conception enables the DLA6 to reach 55Hz without the need of a subwoofer and to deliver a flat frequency response up to 20kHz (+/- 3dB).
The simplicity of the unique patent pending Three Points Rigging system offers easy stacking as well as easy flying and fits in any situation. Setting up the array angle is very easy with the exclusive bended back plate. Angles extension: 0° to 8° for each DLA6 (Angle Step: 0.5° until 4°, 1° until 8°).
| Frequency response | 55Hz – 20’000Hz |
| Maximum SPL peak | 128dB |
| Coverage | Horizontal: 100° – Vertical: Varies with array length and array configuration |
| Low frequency | 2x 6.5″ long excursion, low distortion cone driver |
| Nominal Impedance | 16 Ohms |
| Power Handling | 250W RMS (AES) |
| High frequency | 1x 1,4″ exit, 3″ diaphragm compression driver, loaded with patented waveguide |
| Nominal Impedance | 16 ohms |
| Cabinet Size (WxHxD) | 730 x 180 x 460mm |
| Cabinet finish | 15mm plywood, black epoxy painted, other colours on request |
| Rigging | Patent Pending Three Point Rigging system |
| Protective grill | Removable perforated 1,6mm steel, foam cover |
| Weight | 25Kg |
