The DLA3 Compact Micro Line Array Loudspeaker is a Light, Simple and Versatile product designed to deliver Great Sound into small and even large venues. The DLA3 is a one way full range Line Array consisting of 2 x 3” full range cone driver.
It’s specific conception enables the DLA3 to reach 150 Hz and to deliver a flat frequency response up to 18kHz (+/- 3dB). The versatility of the DLA3 stands in it’s micro size and can be used in many audio application requiring high SPL and clarity!
No compromise between size and sound, It’s just Small and Powerfull!!
| Frequency response | 150Hz – 18’000Hz |
| Maximum SPL peak | 110dB |
| Coverage | Horizontal: 110° Vertical: Varies with array length and array configuration |
| Low frequency | 2x 3″ long excursion, low distortion cone driver |
| Nominal Impedance | 16 Ohms |
| Power Handling | 60W RMS (AES) |
| Connectors | 2 x BNC (wired in parallel) |
| Cabinet Size (WxHxD) | 199 x 92 x 130mm |
| Cabinet finish | 12mm plywood, black epoxy painted, other colours on request |
| Rigging | Patent Pending 4 Points Rigging system |
| Protective grill | Removable perforated 1,6mm steel, foam cover |
| Weight | 14Kg |
